Silver solder PSr 50
Silver solder PSr 50 from Ecotec is a eutectic Ag-Cu alloy with a melting point of 779°C, ideal for high-temperature joints.
Description: PSr 50 solder is a two-component silver-copper alloy.
Regulatory documentation: PSr 50 solders are manufactured in accordance with GOST 19738-2015, PSr 50 wire — GOST 19746-2015, PSr 50 strip — GOST 19739-2015.
Chemical composition of silver solders:
|
Solder grade |
Chemical composition, % |
|||||||||||||
|
Ag |
Cu |
Zn |
Sn |
Mn |
Sb |
P |
Cd |
Ni |
Pb |
Impurities not more than |
||||
|
Pb |
Fe |
Bi |
Sum of determined impurities |
|||||||||||
|
PSr 50 |
50.0±0.5 |
Balance |
— |
— |
— |
— |
— |
— |
— |
— |
0.005 |
0.15 |
0.005 |
0.15 |
Solder dimensions:
|
Solder grade |
Thickness, mm |
Width, mm |
Length, mm |
|||
|
Min |
Max |
Min |
Max |
Min |
Max |
|
|
PSr 50 |
0.1 |
5 |
50 |
200 |
100 |
400 |
Wire diameter:
|
Wire grade |
Diameter, mm |
|
|
Min |
Max |
|
|
PSr 50 |
0.15 |
6 |
Melting point, density, and electrical resistivity:
|
Solder grade |
Density, kg/m3 |
Melting point, K (°C) |
Electrical resistivity, 10-3 Ohm·m |
|
|
Upper critical point |
Lower critical point |
|||
|
PSr 50 |
9300 |
1133 (860) |
1052 (779) |
2.5 |
Applications:
Solder PSr 50 is used for tinning and soldering copper, copper and copper-nickel alloys, nickel, Kovar, nickel silver, brasses and bronzes, soldering titanium and titanium alloys with stainless steel.
